Latest MultiPlus-II 48/5000/70-95 120 volt

Victron Energy MultiPlus-II PMP482505110 48/5000/70-95 120V inverter/charger with 5000VA true sine wave output, 70A battery charging, 95A transfer switch, ESS functionality, PowerControl, PowerAssist, and VE.Bus system integration for 48V marine, mobile, off-grid, backup, and energy storage systems.

The Victron MultiPlus-II PMP482505110 is a 48V, 120V inverter/charger that combines the functions of a MultiPlus with ESS energy storage functionality. It integrates a true sine wave inverter, adaptive battery charger, and automatic transfer switch in one unit for professional marine, yachting, vehicle, and land-based off-grid applications.

PowerControl and PowerAssist help manage limited grid, shore, or generator power. The MultiPlus-II can account for other AC loads and use available remaining power for battery charging, helping prevent overload of the AC source. During short periods of peak demand, PowerAssist can supplement the AC source with battery power, then use spare power to recharge the battery once the load decreases.

The MultiPlus-II can be used in off-grid and grid-connected PV systems and is compatible with both solar charge controllers and grid-tie inverters. It also supports parallel, split-phase, and three-phase operation with compatible units, making it suitable for expandable Victron power systems.

Key Features

• 48V DC inverter/charger for 120V AC systems
• MultiPlus-II design with ESS energy storage functionality
• 5000VA true sine wave inverter output
• 4000W continuous output at 25°C
• 9000W peak power
• 70A maximum battery charge current
• 95A transfer switch
• 95A maximum AC input current
• PowerControl and PowerAssist
• Optional external AC current sensor support up to 100A
• Main AC output has no-break functionality
• Transfer to inverter power in less than 20 milliseconds
• Second AC output is live only when AC input is available
• Compatible with off-grid and grid-connected PV systems
• Compatible with solar charge controllers and grid-tie inverters
• Supports parallel, split-phase, and three-phase operation
• VE.Bus communication port for system integration, remote monitoring, and expanded configurations
• Programmable relay
• Two general-purpose communication ports
• Remote on/off capability
• Fan-assisted cooling
• UL1741 listed
• Compatible with Victron GX devices, VRM Portal, VRM app, VE.Bus Smart Dongle, MK3-USB interface, Digital Multi Control Panel, and VictronConnect app

Technical Specifications

• Manufacturer: Victron Energy
• Model: MultiPlus-II 120V 48/5000/70-95
• Part Number: PMP482505110
• DC System Voltage: 48V
• DC Input Voltage Range: 38V to 66V
• AC Output Voltage: 120VAC ± 2%
• Output Frequency: 60Hz ± 0.1%
• Continuous Output Power at 25°C: 5000VA / 4000W
• Continuous Output Power at 40°C: 3700W
• Continuous Output Power at 65°C: 3000W
• Peak Power: 9000W
• Maximum Efficiency: 96%
• Zero Load Power: 15W
• Zero Load Power in AES Mode: 10W
• Zero Load Power in Search Mode: 3W
• Transfer Switch Rating: 95A
• Maximum AC Input Current: 95A
• AC Input Voltage Range: 90V to 140VAC
• AC Input Frequency Range: 55Hz to 65Hz
• Absorption Charge Voltage: 57.6V
• Float Charge Voltage: 55.2V
• Storage Mode Voltage: 52.8V
• Maximum Battery Charge Current: 70A
• Battery Temperature Sensor: Yes
• Auxiliary Output: 48A
• External AC Current Sensor: Optional, 100A
• Programmable Relay: Yes
• VE.Bus Communication Port: Yes
• General Purpose Communication Ports: 2
• Remote On/Off: Yes
• Operating Temperature Range: -40°C to +60°C / -40°F to 140°F
• Cooling: Fan-assisted
• Humidity: Maximum 95%, non-condensing
• Enclosure Material and Color: Steel, blue RAL 5012
• Protection Category: IP22
• Battery Connection: M8 bolts
• AC Connection: 35 mm² / 2 AWG
• Dimensions: 676 x 330 x 164 mm / 26.6 x 13.0 x 6.5 in
• Weight: 32 kg / 71 lb
• Listing: UL1741
• Safety Standards: EN-IEC 60335-1, EN-IEC 60335-2-29, CSA 22.2 107.1-16
• Emission and Immunity Standards: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3

Applications

• Marine electrical systems
• Yachting power systems
• Vehicle power systems
• Land-based off-grid systems
• Energy storage systems
• Grid-connected PV systems
• Backup power systems
• Generator-assisted systems
• Shore power systems
• Critical-load backup installations
• Larger 48V battery-based 120V AC systems

Ideal For

• 48V battery systems requiring higher-capacity 120VAC output
• Professional marine, mobile, and off-grid installations
• Systems that need inverter, charger, and transfer switch functions in one unit
• Installations using limited shore, generator, or grid power
• Victron-based ESS and solar-supported power systems
• Users who need remote monitoring and system integration through Victron GX and VRM
• Systems requiring expandable parallel, split-phase, or three-phase capability
• Applications with larger AC loads that exceed the capacity of smaller 3000VA inverter/chargers

Protection Features

• Output short-circuit protection
• Overload protection
• Battery voltage too high protection
• Battery voltage too low protection
• Temperature too high protection
• Protection against 120VAC on inverter output
• Input voltage ripple too high protection

System Compatibility

• Compatible with 48V battery systems
• Designed for 120VAC systems
• Compatible with off-grid PV systems
• Compatible with grid-connected PV and alternative energy systems
• Compatible with solar charge controllers
• Compatible with grid-tie inverters
• Supports VE.Bus communication
• Supports parallel operation with compatible Victron Multi units
• Supports split-phase operation with two units of the same model
• Supports three-phase operation with three units of the same model
• Compatible with Cerbo GX, Ekrano GX, and other compatible GX devices for VRM remote monitoring
• Compatible with VE.Bus Smart Dongle for Bluetooth monitoring and control
• Configurable with VEConfigure software using an MK3-USB interface
• Supports optional 100A external current sensor for PowerControl, PowerAssist, and self-consumption optimization

Check Before Ordering

• Confirm your system uses a 48V DC battery bank.
• Confirm your loads and installation are designed for 120VAC output.
• Verify that 4000W continuous output and 9000W peak power are suitable for your connected loads.
• Confirm the battery bank can safely accept up to 70A charging current.
• Confirm whether the 95A transfer switch and 95A maximum AC input current match your AC system design.
• Confirm whether your application requires ESS functionality, grid-parallel operation, or off-grid operation.
• Check whether an external current sensor or power meter is needed for self-consumption optimization or grid-feed control.
• Verify installation requirements for AC wiring, DC wiring, overcurrent protection, grounding, ventilation, and clearances.
• Confirm whether monitoring or configuration accessories such as a GX device, VE.Bus Smart Dongle, MK3-USB interface, or Digital Multi Control Panel are required.
• For parallel, split-phase, or three-phase systems, confirm that all units are the same compatible model and are configured correctly.
